| High-precision Cut-to-size Saw for Non-ferrous Metals Type-FLM |
|
 |
|
Feeder travel speed : |
|
|
|
forward |
up to 25 m/min |
up to 82 ft/min |
|
back |
25m/min |
82 ft/min |
|
Saw travel speed : |
|
|
|
forward |
0 - 50 m/min |
0 - 164 ft/min |
|
back |
50 m/min |
164 ft/min |
|
Clamp opening : |
|
|
|
|
135 mm |
5.31“ |
|
Main saw motor power :
|
|
|
|
|
21 kW |
32 HP |
|
Main saw blade : |
|
|
|
Diameter max. |
450 mm |
17.71“ |
|
Projection max. |
130 mm |
5.11“ |
|
Cutting height |
dep. on material/blade type |
|
|
Weight : |
|
|
|
FLM 330 |
Approx. 8000 kg |
17,600 lbs |
|
FLM 430 |
Approx. 9000 kg |
19,800 lbs |
|
FLM 580 |
Approx. 10000 kg |
22,000 lbs |
|
Cutting length : |
|
|
|
FLM 330 |
3230 mm |
127" |
|
FLM 430 |
4230 mm |
166" |
|
FLM 580 |
5730 mm |
225" | |
Benefits/Features FLM
Highest accuracy (standard +- 0,1 mm, option +- 0,05 mm)
Highest productivity through Schelling turntable solution
Highest cleanness through Schelling chip conducting system (99,5% chiplessness)
|
