| High-precision Cut-to-size Saw for Non-ferrous Metals Type-FSM |
|
 |
|
Feed travel speed : |
|
|
|
forward |
up to 20 m/min |
66 ft/min |
|
back |
20 m/min |
66 ft/min |
|
Saw travel speed : |
|
|
|
forward |
0,2 - 60 m/min |
0,32 - 98 ft/min |
|
back |
50 m/min |
164 ft/min |
|
Clamp opening : |
|
|
|
|
210mm |
8 2/10“ |
|
Main saw motor power : |
|
|
|
|
63 kW |
84 HP |
|
Main saw blade : |
|
|
|
Diameter |
680 mm |
26 7/10“ |
|
Projection |
215 mm |
8 4/10“ |
|
Max. book height |
200 mm |
7 8/10" |
|
Weight : |
|
|
|
FSM 430 |
ca. 14.000 kg |
|
|
Cutting length : |
|
|
|
FSM 330 |
3300 mm |
129" |
|
FSM 430 |
4300 mm |
169" |
|
FSM 630 |
6300 mm |
248" | |
Benefits/Features FSM
Highest cut performance (AL 5083 thickness 120 mm, 3 m/min forward feed)
Highest accuracy (standard +- 0,1 mm, option +- 0,05 mm)
Highest productivity through Schelling turntable solution
Highest cleanness through Schelling chip conducting system (99,5% chiplessness)
|
